Version

CA50


Waste Therapy

Medical Waste Incineration Therapy

Feed Ability

Regular 100 kgs per feeding

Burning Price

Normal 50 kgs per individual resources

Burning Time per Feed

Average 2 hr

Control Placing

PLC( Programmable Reasoning Controller Incinerator)

Voltage

220V

Power

1.0 Kw

Gas

Diesel oil

Heater

Italy Burner

Feed Setting

Guide

Temperature Level Degree Screen

Digital Present

Fuel intake (Oil)

Typical 16.9 Kgs/Hour

Interior Capacities

100x80x70cm (Key Chamber)

External Dimensions

230 x 130 x 155cm (text)

Waste melting chamber

560Liters

Message Burning Chamber

280Liters

Oil Container Capability

200 Litres

Door Opening

70 x 50cm

Smokeshaft

5.0 M

Gross Weight

4500kgs

Chamber Product

Firebrick, Refractory Concrete

Max.

Treatment Technical Specifications

Solid Chamber temperature level

8000C -10000 C

Gas Chamber temperature

10000C -12000 C

Chamber Anti-Rate

17500C

Residency time

2.0 Sec.

2.0 Sec.

Burning effectiveness

＞ 98 percent

Waste Lower Calorific Power
