1. For clinic,lab, small hospital with low waste output capacity, no condition with other medical waste treatment(Underdeveloped country or area, or emergency situations ).

2. Doctor, nurse treat the syringes, needle, infusion set immediately after use, plug to play, no dispersion risk.

3. melting the syringes needle with 1250Celsius high temperature to metal slag, sterilization immediately. Destroy syringes, infusion set, can not use again.

Medical Needle Incinerator: Melt the needle waste, cut off syring tube with needle, cut off the infusion tube.

Model SYC19, Price: $110usd/set, MOQ: 5 sets.

EXW factory term(donot including shipping cost)

Purchase email:  info@hiclover.com

Qustion1: If request 1-4 set only, how to do?

Answer: We will plus $50-$200usd fee per order.

Qustion2: If request more than 5 sets only, any discount?

Answer: We will  supply discount quotation accordingly.

---

Incinerator Items/Model	HICLOVER TS5(PLC)	HICLOVER TS10(PLC)	HICLOVER TS20(PLC)	HICLOVER TS30(PLC)
Burn Rate (Average)	5-10 kg/hour	10-20 kg/hour	20-30 kg/hour	30-50 kg/hour
Feed Capacity(Average)	10kg/feeding	20kg/feeding	40kg/feeding	60kg/feeding
Control Mode	PLC Automatic	PLC Automatic	PLC Automatic	PLC Automatic
Combustion Chamber	52L	100L	210L	330L
Internal Dimensions	50x35x30cm	50x50x40cm	65x65x50cm	75x75x60cm
Secondary Chamber	26L	50L	110L	180L
Smoke Filter Chamber	Yes	Yes	Yes	Yes
Feed Mode	Manual	Manual	Manual	Manual
Voltage	220V 2P	220V 2P	220V 2P	220V 2P
Power	0.5Kw	0.5Kw	0.5Kw	0.5Kw
Burner Type	Italy Brand	Italy Brand	Italy Brand	Italy Brand
Oil Consumption (kg/hour)	4	6	8	12
Gas Consumption (m3/hour)	6.2-11.4	6.2-11.4	8-15.7	9.8–20
Temperature Monitor	Yes	Yes	Yes	Yes
Temperature Thermometer	Corundum Probe Tube	Corundum Probe Tube	Corundum Probe Tube	Corundum Probe Tube
Temperature Protection	Yes	Yes	Yes	Yes
Automatic Cooling	Yes	Yes	Yes	Yes
Automatic False Alarm	Yes	Yes	Yes	Yes
System Testing Model	Yes	Yes	Yes	Yes
Time Setting	Yes	Yes	Yes	Yes
Progress Display Bar	LCD Display	LCD Display	LCD Display	LCD Display
Oil Tank	200L	200L	200L	200L
Oil Tank Stand	190cm Height	190cm Height	190cm Height	190cm Height
Liquid level Display	Yes	Yes	Yes	Yes
Feeding Door	20x20cm	30x30cm	45x40cm	55x50cm
Chimney	2Meter	3Meter	3Meter	5Meter
Chimney Type	Stainless Steel 304	Stainless Steel 304	Stainless Steel 304	Stainless Steel 304
1st. Chamber Temperature	800℃–1000℃	800℃–1000℃	800℃–1000℃	800℃–1000℃
2nd. Chamber Temperature	1000℃-1300℃	1000℃-1300℃	1000℃-1300℃	1000℃-1300℃
Residency Time	2.0 Sec.	2.0 Sec.	2.0 Sec.	2.0 Sec.
Gross Weight	1000kg	1500kg	2200kg	3000kg
External Dimensions	120x80x110cm	140x90x120cm	160x110x130cm	175x120x140cm

1. N95 and Disposable Mask Machine



2. 400mm and 1600mm Melt blown Production Line

3. ES Fiber Production Line







N95 Face Mask Machine Production Line

Melt blown Production Line



A.)Optional Capacity: 1600mm

Efficiency: 95-97%

FOB Term Price: USD per set

Price Valid: 5days.

Ave.60 Days ready for shipping.

In stock Price: USD per set





B.)Optional Capacity: 400mm

Efficiency: 40-50% .

FOB Term Price: USD per set

Price Valid: 5days.

Ave.20 Days ready for shipping.

Payment: TT 70% In advance, TT 30% before leave factory

Shipping: 1*20′ container per set, Ave. 2000Kgs.



Main Parts: Extruder, mold, winder, oven, ultrasonic

Daily Capacity：100-150Kgs/24Hours

Screw extruder：100-150Kgs

Motor power: 15KW frequency conversion speed regulation
Reducer speed ratio: 1:10 or 1:16
Screw length to diameter ratio: 30: 1
Screw diameter: 50mm
Winding machine diameter: ￡ 630mm
Winding machine drive motor power: 0.55kw
Speed ratio of winder drive reducer (if any): 1:71
Air heater power: 15kw
Power of vacuum calciner: 12kw
The size of vacuum calciner: 500 × 300 × 200
Ultrasonic power: 1800, frequency 28kHZ
Ultrasonic sink size: 800 × 300 × 250





HICLOVER – Medical Environmental

---



WWW.HICLOVER.COM

Waste Incinerators

Medical Waste Incinerator

Pet Animal Cremation

Solid Waste Incinerator

Tel:  +86-25-8461 0201

Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: sales@hiclover.com
Email: hicloversales@gmail.com

Nanjing Clover Medical Technology Co.,Ltd.



2020-04-20

N95 Face Mask Machine Production Line on Sale Now! $250,000USD per set

N95 Face Mask Machine Production Line on Sale Now! $250,000USD per set

l Dimension(L*W*H): 1037*855*1780

l Power Supply 15.3kw mono phase

l Net Weight: approx.: 1500kg

HICLOVER – Medical Environmental

---



WWW.HICLOVER.COM

Waste Incinerators

Medical Waste Incinerator

Pet Animal Cremation

Solid Waste Incinerator

Tel:  +86-25-8461 0201

Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: sales@hiclover.com
Email: hicloversales@gmail.com

Nanjing Clover Medical Technology Co.,Ltd.



2020-04-10

平面口罩机参数：

Semi-Automatic Mask Machine

l Power supply: 3.3KW mono phase

l Mask Size: 175mm*80-100mm (two or three layers)

l Nonwoven (GMS): 10-50g

l Capacity: 120 to 150pcs/min

l Dimension(L*W*H):3800mm*500mm*1400mm

l Net Weight: about 1000kg

焊接机参数：

Welding Machine

l Capacity: 5 to 10pcs/min

l Power supply: 8.5KW mono phase

l Compressed Air connection: 0.5 to 0.7Mpa

l Dimension(L*W*H): 900mm*650mm*1380mm

l Net weight: approx. 50kg

KN95口罩机参数：

N95 Mask Machine

l Capacity: 130 to 160pcs/min

l Dimension(L*W*H): 1037*855*1780

l Power Supply 15.3kw mono phase

l Net Weight: approx.: 1500kg

50kgs per hour incinerator with two chambers suppliers from china

*Aveage 50kgs per hour

*Double chamber and double burner

*900liters primary combustion chamber

*Italy burner

*Stainless steel chimney

Model	YD-50
Burning Rate	Average 50 kgs/hour
Feed Capacity	Average 150 kgs
Primary Combustion Chamber	900 Liters
Secondary Combustion Chamber	300 Liters
Mix Combustion Chamber	Yes
Smoke Filter Chamber	Yes
Feed Mode	Manual
Voltage	220V/380V
Power	0.7Kw
Fuel Type	Diesel Oil/ Natural Gas/LPG
Burner	Italy Original
Oil Consumption (Diesel Oil)	12.1--23.9 kg/hour
Gas Consumption (Natural Gas)	9.9--26.1 m3/hour
Internal Dimensions	120 x 90 x 85cm (primary chamber)
External Dimensions	200 x 160 x 310cm (without chimney)
Temperature Monitor	Yes
Oil Tank Capacity(if oil fuel)	300 Liters
Door Opening	62 x 80cm
Chimney Length	5.0 Meters
Chimney Type	Stainless Steel
Equipment Gross Weight	5500 kgs
Operation Technical Specifications
Primary Chamber Temperature	800℃–-1000℃
Secondary Chamber Temperature	1000℃-1200℃
Residency Time	2.0 Sec.
Burning Efficiency	＞98%
Waste Lower Calorific Power	3000Kcal
