Doubel Combustion Chamber

All Incinerators are Doubel Combustion Chamber with One Fuel Burner Each. After Burner Technology for Completely Combustion and Cleaner World.

Read More

High Temperature Incineration

Temperature Range 800 Degree to 1200 Degree in Combustion Chamber. Temperature Thermocouple Monitor and Controller. High Quality Fire Brick and Refactory Cement.

Read More

Get Lastest News

There are latest incinerator news like technical, public news, business tender for medical waste incinerator,animal incineration, pet cremation

Read More

Nanjing Clover Medical Technology Co.,Ltd.

Email: sales@clover-incinerator.com | Tel: +86-25-8461 0201

Latest Product

Regular model incinerator for market with burning rate from 10kgs to 500kgs per hour and we always proposal customer send us their require details, like waste material, local site fuel and power supply, incinerator operation time, etc, so we can proposal right model or custom made with different structure or dimensions.
Incinerator Model YD-100 is a middle scale incineration machine for many different usage: for a middle hospital sickbed below 500 units, for all small or big size family pets (like Alaskan Malamute Dog), for community Municipal Solid Waste Incineration, etc. The primary combustion chamber volume is 1200Liters (1.2m3) and use diesel oil or natural gas fuel burner original from Italy.

Latest Post

INCINERATOR SPECIFICATION Capacity UPTO 20 kg/hr


Size:  940 x860x2700 mm
Material:  STAINLESS STEEL STACK, REFRACTORY CONCRETE LINING SPECIAL INSULATION MATERIAL
With burner:  15 C 20 KW
Temperature:   PRIMARY CHAMBER = 800°C AND SECONDARY CHAMBER = 850 – 1200° C
Sufficient heat generation for secure and complete combustion 600-800 °C in the first chamber and >1000 °C in the second chamber
Easy transportation on standard EURO-pallets
Constructed in a modular fashion  easy on-site movement and assembly with a minimum of equipment and technical skills;
For the destruction of problematic waste like sharps, amputates and body parts, wet or moist matter;
Off-gas quality: moderate smoke emissions during one quarter of the total incineration time; no visible emission during three quarters. AS PER INTERNATIONAL STANDARDS
The remaining ash approximately 5-10% in weight and below 1% in volume of the original waste AS PER INTERNATIONAL STANDARDS
Chimney height at least 5 m above the incinerator 5m ABOVE FROM THE GROUND
Temperature resistance of the lining  at least 1,200 °C


N.D. could get Ebola waste from Calif..


FARGO, N.D. — California health officials have given notice that North Dakota is one of six states that could receive Ebola medical waste in case the state has any substance to incinerate.

In a notice posted last week, the California Department of Public Health listed North Dakota as one of six states where California sends medical waste to be incinerated when onsite disposal isn’t available at medical centers.

Healthcare Environmental Services Inc., located at a nearby park at 1420 40th St. N. at Fargo, operates a medical waste incinerator that also accepts waste from other locations.

Calls to Healthcare Environmental Services on Tuesday afternoon were not returned. A Sanford spokeswoman said it could not immediately comment on the possible incineration of Ebola waste from California at the Fargo facility.

In another development, public health officials are tracking two North Dakota residents who recently returned from countries in West Africa that are battling the Ebola epidemic.

Neither of those two residents is running a fever or showing any symptoms of an Ebola infection, which can include diarrhea, joint and muscle aches and abnormal bleeding.

“They’ve just recently traveled to the area,” said epidemiologist Michelle Feist of the North Dakota Health Department. “They pose no danger to the community.”

Health officials are not releasing information about where both people reside.

Public health officials in Minnesota and South Dakota are also tracking residents in those states who have recently visited Guinea, Liberia or Sierra Leone in West Africa, where an outbreak of Ebola has killed about 5,000.

State health officials are contacted by the Centers for Disease Control and Prevention when a person is entering the United States from these countries through five major international airports.

“We’re doing tracking,” said Sam Brungardt, a public information officer for the Minnesota Health Department.

On Monday, Minnesota health officials declared that they were tracking one resident who had traveled to West Africa, but the list of individuals to track is growing.

“It has grown, and it’ll continue to rise as we get reports from the CDC,” Brungardt said. “There’s people who are coming from these three West African countries daily.”

So far, not one of those being monitored for signs of fever with twice-daily temperature checks show any sign of infection, he said.

As a precaution, however, they will continue to be checked during the 21-day monitoring period, generally regarded as the incubation period for the Ebola virus.

South Dakota health officials are also monitoring somebody who recently returned from West Africa, but isn’t showing symptoms.

by: http://bismarcktribune.com/news/state-and-regional/n-d-could-receive-ebola-waste-from-calif/article_10e0e242-5f2c-11e4-8ff8-8ba8bab48ce3.html

South Dakota health officials also are monitoring someone who recently returned from West Africa, but is not showing symptoms.

by: http://bismarcktribune.com/news/state-and-regional/n-d-could-receive-ebola-waste-from-calif/article_10e0e242-5f2c-11e4-8ff8-8ba8bab48ce3.html


Norfolk incinerator bill wrangle could continue until after Christmas


Norfolk County Council voted by 48 votes to 30 to terminate the contract for the proposed incinerator at Saddlebow in an extraordinary meeting in April.

Council officers had said that, due to delays in securing planning permission, the contentious project no longer provided good value for money, and councillors agreed to ditch it.

In May, the estimated cost of cancelling the contract was put at just over #33.7m. That included #20.3m to Cory Wheelabrator – the company that would have built and run the burner; public question costs of #1.6m and estimated interest rate associated expenses of #11.8m.

The first #11.8m of this bill was paid in July, but council bosses are locked in months of discussions about the fine details of the contract and how much that means the council must pay Cory Wheelabrator.
In September, it was announced the compensation will be”substantially lower” than the #20.3m originally estimated.

But in a meeting this week, Tom McCabe, interim director of environment, transport and development in Norfolk County Council, told councillors that the final figure had yet to be agreed.

He said:”The conversation with Cory Wheelabrator is continuing and we would expect to have it resolved by Christmas.

“It is premature to say it will be done by then, however. It could be done before that it could drag on for more.”
Norfolk County Council is still trying to come up with a long-term solution to how to deal with the county’s waste.

But, in the short-term, a deal has been struck by their counterparts in Suffolk for rubbish to be burnt at a newly-built incinerator in Great Blakenham.

Over the next year, about 40,000 tonnes of Norfolk’s residual household waste will be hauled down the A140 to be burned at the plant.

• What do you think about the incinerator saga?


Supply, Installation and Commissioning of DIESEL FIRED INCINERATORS


Supply, Installation and Commissioning of DIESEL FIRED INCINERATORS
Medical Waste Incinerator, 100 to 120 Kg/hr
Application   For incineration, general and pathological
Capacity    100 C 120 kg/h burn rate
Type Two  combustion chambers type; primary  and Secondary, controlled/forced combustion air type with a flue gas emission scrubbing unit
Operating time                Minimum 8 hours daily
Operating temperature     From 850 0C to 1200 0C, Automatic controlled
Residual Ash                    5 to 10%
Construction Constructed from heavy duty mild or aluminized  steel
Or equal and approved equivalent

Insulation material            Refractory material lining similar or equal to calcium
Silicate and hot face combination of heavy duty brickwork
Internal Construction        Fixed hearth type complete with gratings, concave bottom and charging door, lined with refractory material
Charging Door                   Suitable for manual loading of wastes and with smooth
Dear seal equivalent of Ceramic seals with hinges.
Door Lock                          Automatic, Electric type
Ash removal door    Provided, for removing resultant bottom ash leftovers                              from the Primary chamber
Gratings    Provided
Loading Manual loading of waste
Primary Burner                        Fully automatic, with fuel, temperature and speed  controls with ignition system  flame detector                                                         Air fan Complete with safety features, flame failure                                                                    Diesel fired fuel injector type
Flange mounted
Blower   Provided.  3 phase for supplying excess combustion air through the distribution system with speed control system
Temperature Minimum exit 850 0C
Observation port To be provided with protective glass type
     3.3    Secondary chamber


Medical Syringe and Destroyer-Needle Destroyer-Needle Incinerators

1. For clinic,lab, small hospital with low waste output capacity, no condition with other medical waste treatment(Underdeveloped country or area, or emergency situations ).
2. Doctor, nurse treat the syringes, needle, infusion set immediately after use, plug to play, no dispersion risk.
3. melting the syringes needle with 1250Celsius high temperature to metal slag, sterilization immediately. Destroy syringes, infusion set, can not use again.
Medical Needle Incinerator: Melt the needle waste, cut off syring tube with needle, cut off the infusion tube.
Model SYC19, Price: $110usd/set, MOQ: 5 sets.
EXW factory term(donot including shipping cost)
Purchase email:  info@hiclover.com
Qustion1: If request 1-4 set only, how to do?
Answer: We will plus $50-$200usd fee per order.
Qustion2: If request more than 5 sets only, any discount?
Answer: We will  supply discount quotation accordingly.

Incinerator Items/Model HICLOVER TS5(PLC) HICLOVER TS10(PLC) HICLOVER TS20(PLC) HICLOVER TS30(PLC)
Burn Rate (Average) 5-10 kg/hour 10-20 kg/hour 20-30 kg/hour 30-50 kg/hour
Feed Capacity(Average) 10kg/feeding 20kg/feeding 40kg/feeding 60kg/feeding
Control Mode PLC Automatic PLC Automatic PLC Automatic PLC Automatic
Combustion Chamber 52L 100L 210L 330L
Internal Dimensions 50x35x30cm 50x50x40cm 65x65x50cm 75x75x60cm
Secondary Chamber 26L 50L 110L 180L
Smoke Filter Chamber Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual
Voltage 220V 2P 220V 2P 220V 2P 220V 2P
Power 0.5Kw 0.5Kw 0.5Kw 0.5Kw
Burner Type Italy Brand Italy Brand Italy Brand Italy Brand
Oil Consumption (kg/hour) 4 6 8 12
Gas Consumption (m3/hour) 6.2-11.4 6.2-11.4 8-15.7 9.8–20
Temperature Monitor Yes Yes Yes Yes
Temperature Thermometer Corundum Probe Tube Corundum Probe Tube Corundum Probe Tube Corundum Probe Tube
Temperature Protection Yes Yes Yes Yes
Automatic Cooling Yes Yes Yes Yes
Automatic False Alarm  Yes Yes Yes Yes
System Testing Model Yes Yes Yes Yes
Time Setting Yes Yes Yes Yes
Progress Display Bar LCD Display LCD Display LCD Display LCD Display
Oil Tank 200L 200L 200L 200L
Oil Tank Stand 190cm Height 190cm Height 190cm Height 190cm Height
Liquid level Display  Yes Yes Yes Yes
Feeding Door 20x20cm 30x30cm 45x40cm 55x50cm
Chimney 2Meter 3Meter 3Meter 5Meter
Chimney Type Stainless Steel 304  Stainless Steel 304  Stainless Steel 304  Stainless Steel 304
1st. Chamber Temperature 800–1000 800–1000 800–1000 800–1000
2nd. Chamber Temperature 1000℃-1300℃ 1000℃-1300℃ 1000℃-1300℃ 1000℃-1300℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1000kg 1500kg 2200kg 3000kg
External Dimensions 120x80x110cm 140x90x120cm 160x110x130cm 175x120x140cm
